Tunnel Dryer for Mono-Setting System
Technological Functions
The drying process is to remove the free water out of the wet green body by evaporation, it improves the strength and reduce the damage of the green body, also accelerates the cycle of the firing process, which lead to more energy efficient production
A fully automatic dryer is a continuous drying equipment, to reduce labor intensity and accelerate the drying of products.
The design of the dryer follows the principle of thermal engineering while complements the drying process to higher performance. Green body receives moisturization, heating, rapid dehydrating, and balanced drying, making it an overall efficient, safe and stable process.
Structure and Principles
Including:
Dryer body.
Green body storage chamber.
Drying chamber with automatic lifting doors.
Thermal generator.
Humidification system.
Heat supply system.
Hot air mixing system.
Exhaustion system.
Fully automatic control system.
Features
In line with the principle of dry thermal design .
Complete thermal system,
the tide exhaust system,
circulatory system.
Intelligent control the
whole process.
Low power consumption
and high efficiency.
Fewer defects.
Continual Dryer for Double Setting
Technological Functions
The drying process is to remove the free water out of the wet green body by evaporation, it improves the strength and reduce the damage of the green body, also accelerates the cycle of the firing process, which lead to more energy efficient production
A fully automatic dryer is a continuous drying equipment, to reduce labor intensity and accelerate the drying of products.
The design of the dryer follows the principle of thermal engineering while complements the drying process to higher performance. Green body receives moisturization, heating, rapid dehydrating, and balanced drying, making it an overall efficient, safe and stable process.
Structure and Principles
Including:
Dryer body.
Green body storage chamber.
Drying chamber with automatic lifting doors.
Thermal generator.
Humidification system.
Heat supply system.
Hot air mixing system.
Exhaustion system.
Fully automatic control system.
Features
In line with the principle of dry thermal design .
Complete thermal system,
the tide exhaust system,
circulatory system.
Intelligent control the
whole process.
Low power consumption
and high efficiency.
Fewer defects.
Moisturizing Chamber
Technological Functions
Moisturization is a key production is a key part of the product after molding, in order to avoid the sharp evaporation of water caused by the cracking of the blank body.
Our modern fully automatic continuous moisturizing channel design will be moisturized with the same concept to implement, so that it becomes an integral part of the whole drying, in accordance with the drying process and thermal principles, to meet the initial drying process control requirements, to provide humidity and temperature relative to the temperature of space, to avoid drying early prone to cracking, Essential requirements for fast drying.
Structure and Principles
Customer according to our drawings, on-site self-construction;
Good insulation moisturizing;
The kiln top load-bearing and insulation meet the design requirements;
Independent moisturizing channel design;
To meet the requirements of the initial drying process control;
Provides room for relatively stable humidity and temperature to avoid easy cracking in the early drying phase;
Configure the stirring air cone;
Humidity, temperature sensors;
Moisture and heating systems.
Features
The integrated control system of each control unit allows the thermal air flow and humidity to move around according to the design requirements and meet the process requirements.
temperature display, regulation;
Humidity display, adjustment;
Heat-sending air scale adjustment;
Moisture scale adjustment
